Notes for KiCAD

GERBER FILES

  • Can compare different Gerbers online at Altium
  • Try comparing split out new Control Board, vs old Control Board

ADDING PROJECT SYMBOLS

  • New project
  • In KiCad menu window, Symbol Editor
    • File -> New Library
      • Project level
      • Add _project_parts folder
      • Name _project
    • Copy all symbols used in project from global library to local project library. Ensures any changes in the global library do not affect the project. Rather than add R / C / RV / etc, I just added new items like Arduino_Pro_Mini, etc
      • Devices section has all common items
      • Right-click, Copy
      • Go to project library _project
      • Right-click, Paste
  • To change symbol
    • Go to item on schematic, double-click
    • Select Change Symbol… and select new library identifier as above, e.g. _project:aruino_pro_mini, etc

FOOTPRINTS

  • Create folder ../_project_parts/footprints.pretty
  • In main KiCad, Preferences, select Manage Footprint Libraries
    • Add new footprints folder above
  • Best to use relative folder paths in projects

3D MODELS

  • To assign a 3D model to a footprint permanently, use FootPrint Editor
    • Double click footprint in Editor
    • Add 3D model via third tab as normal, and Save
    • When add new footprint the 3D model will automatically be associated
    • If existing footprint, double click on footprint and Update from library
