Install Trilium on Docker

This install assumes that Docker has been installed previously, and extends the Docker stack created for the Traefik Reverse Proxy.

Trilium is a notes app that can run on desktop or server. I have it running in desktop mode on the Mac, and sync’d to the server version running in Docker on Titan.

Install Trilium

Create folder for Trilium data:

1
2
3
cd ~/docker
mkdir trilium
mkdir trilium/data

Add the following service definition to dc-trilium.yml in docker root folder:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
version: "3.9"

# NETWORKS ####################################################

networks:
  traefik_proxy:
    external: true

# SERVICES ####################################################

services:

  trilium:
    container_name: trilium
    image: zadam/trilium:latest
    #
    restart: unless-stopped
    #
    networks:
      - traefik_proxy
    #
    volumes:
      - $DOCKERDIR/trilium/data:/home/node/trilium-data
    labels:
      - "traefik.enable=true"
      ## HTTP Routers
      - "traefik.http.routers.trilium-secure.entrypoints=web_https"
      - "traefik.http.routers.trilium-secure.rule=Host(`trilium.$DOMAINNAME_CLOUD_SERVER`)"
      - "traefik.http.routers.trilium-secure.tls=true"
      # Middlewares
      #- "traefik.http.routers.trilium-secure.middlewares=authelia@docker"
      ## HTTP Services
      - "traefik.http.routers.trilium-secure.service=trilium-svc"
      - "traefik.http.services.trilium-svc.loadbalancer.server.port=8080"
This post is licensed under CC BY 4.0 by the author.
