This install assumes that Docker has been installed previously, and extends the Docker stack created for the Traefik Reverse Proxy.
Plex Media Server gives you one place to find and access all the media that matters to you. From personal media on your own server, to free and on-demand Movies & Shows or live TV, to streaming music, you can enjoy it all in one app, on any device. It supports everything from Movies, TV Shows, Home Videos to Music & Photos.
Install Plex Media Server
Create folders for Plex data:
1
2
3
cd ~/docker
mkdir plex
mkdir plex/transcode
Add the following service definition to dc-plex.yml in docker root folder
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
version: "3.9"
# NETWORKS ####################################################
networks:
traefik_proxy:
external: true
# VOLUMES #####################################################
volumes:
cifs_media_mount: # SMB share to //TITAN/media folder
driver: local
driver_opts:
type: cifs
device: //$TRUENAS_SERVER_IP/media
o: "username=$PLEX_USER,password=$PLEX_PASSWORD,vers=3.0,uid=$PUID,gid=$PGID"
# SERVICES ####################################################
services:
plex:
container_name: plex
image: plexinc/pms-docker
#
restart: unless-stopped
security_opt:
- no-new-privileges:true
#
networks:
- traefik_proxy
# devices:
# - /dev/dri:/dev/dri # for harware transcoding
ports:
- 32400:32400/tcp
- 3005:3005/tcp
# - 8324:8324/tcp # Plex for Roku
# - 32469:32469/tcp # Plex DLNA server
# - 1900:1900/udp # Plex DLNA server
- 32410:32410/udp
- 32412:32412/udp
- 32413:32413/udp
- 32414:32414/udp
volumes:
- $DOCKERDIR/plex:/config
- $DOCKERDIR/plex/transcode:/transcode
- cifs_media_mount:/data # Refer to VOLUMES section above
environment:
HOSTNAME: PlexMediaServer
# PLEX_CLAIM_FILE: $PLEX_CLAIM
TZ: $TZ
PLEX_UID: $PUID
PLEX_GID: $PGID
ADVERTISE_IP: "https://plex.$DOMAINNAME_CLOUD_SERVER"
labels:
- "traefik.enable=true"
## HTTP Routers
- "traefik.http.routers.plex-secure.entrypoints=https"
- "traefik.http.routers.plex-secure.rule=Host(`plex.$DOMAINNAME_CLOUD_SERVER`)"
## Middlewares
# - "traefik.http.routers.plexms-secure.middlewares=chain-no-auth@file"
## HTTP Servicesnoauth
- "traefik.http.routers.plex-secure.service=plex"
- "traefik.http.services.plex.loadbalancer.server.port=32400"
From the Docker root folder, run this command to build the container:
1
sudo docker compose -f dc-plex.yml up -d
If you look at the logs, ignore the Critical: libusb_init failed message, associated with not finding the not-installed USB library, apparently associated with DVR functionality
CIFS_MOUNT
- The media files for Plex are stored on the TrueNAS volumes on server TITAN and need to be accessed over an SMB share. This is achieved through the cifs_mount volume in the Docker compose file above
- NOTE: Once a volume is created for the container it cannot be changed, even if the container is rebuilt. If the cifs_mount settings change, it is necessary to delete the container then the image, then re-run the docker compose command
Configure Plex Media Server
- Plex does not offer to setup Media files initially if connected to by a remote server, i.e. Docker. This page describes how to access as “local” via SSH
Resources
- Plex main page (support articles)
- Plex on Docker at hub.docker.com
